Planning 9
The following illustrations show examples of track layouts. These drawings are plan views,
showing the track system as if you were looking at it from above.
L-coupler
L-coupler L-coupler
L-coupler
Coupler
location
TrackKEY:
Figure 5: Simple system
L-coupler
L-couplerL-coupler
L-coupler
T-coupler T-coupler
T-couplerT-coupler
Figure 6: Advanced system
T-coupler
L-coupler
L-coupler
L-couplerL-coupler
T-coupler
T-coupler
T-coupler
T-couplerT-coupler
X-coupler X-coupler
Figure 7: Complex system
