10 - e1 Assembly and User Manual
30596-02A
Stand Upright Assembly
Place the bench approximately where it 1.
will remain, leaving room to work be-
hind it.
Make sure the clevis forks are pointed 2.
up and secure each stand upright to the
rear of the bench pedestals using four
1/4-20 x 1/2” machine screws and four
locknuts.
LOCKNUT
(others hidden)
MACHINE SCREWS
STAND UPRIGHT
To Next Page
