e1 Assembly and User Manual - 17
30596-02A
Remote Connections
Your sunbed incorporates advanced circuit-
ry allowing it to connect and communicate
with most remote control systems. If a re-
mote system is to be used, fi rst determine
whether the remote system is a T-Max® Sys-
tem or a standard remote system operating
with a control relay. The following pages
outline many different remote connection
scenarios. Find the scenario that best fi ts
your application.
Three remote ports are located on the back
of the canopy next to the power cords, two
RJ-22 (4-wire) ports for “daisy-chain” remote
connections and one RJ-11 (6-wire) port for
wireless remote connection.
T-Max® Products
The T-Max® remote systems offer the ulti-
mate in sunbed control, while allowing the
tanner easy, straightforward operation. Your
sunbed is confi gured to directly connect to
this system, including the wireless remote
system. The circuitry inside your sunbed
eliminates the need for the T-Max® 3W (or
the older 1A and 3A) when connecting to
the T-Max® Manager series. Your sunbed
supports the auto addressing feature of the
T-Max® Manager models and many pa-
rameters. See your T-Max® manual for de-
scriptions of these parameters and how they
function.
REMOTE PORTS
RJ-22 RJ-11
wired wireless
T-Max® Wireless Remote System
The T-Max® G2 eliminates wires in your sa-
lon, allowing easy setup without hiring an
electrician to run wires. It also protects your
investment from damage by isolating each
unit from one another. Your sunbed arrives
“wireless ready”, which means it connects
directly to the T-Max® G2 wireless system.
Older tanning beds, and T-Max® managers,
may also utilize this system but require a
T-Max “Power Injector” (PI) to provide the
needed power to the G2 wireless unit.
Remote System Hook-up Scenarios
Follow the diagrams on the next few pages to
see the many different scenarios for hooking
up your salon. If you need further assistance,
call T-Max® directly at (417) 272-0761.
The remote connection is not designed to
supply or accept high voltage, nor can it
provide power to an external timer. The
sunbed’s remote interface circuitry operates
on 5 volts, attempting to connect it to any
higher voltages will damage the sunbed as
well as void your warranty.
CAUTION
