S5 Control Surface/Frame Manual Page 23 Version 1.0 ©1999 Euphonix, Inc.
Dimensions and Weight
Module Weight Width
CM401: 35lbs (16kg) 12”
CM402: 35lbs (16kg) 12”
CM408: 35lbs (16kg) 12”
CM409F: 16lbs (7kg) 12”
CM409H: 9lbs (4kg) 6”
CM409HTP: 10lbs (4.5kg) 6”
Approximately 14 inches of depth should be left behind the System 5 Control
Surface for cable connections.
Technical Specifications
Environmental Requirements
Environmental requirements for the System 5 Control Modules are as follows:
Operating Temperature: 0 to 40 degrees Celsius (ambient)
Storage Temperature: -10 to 55 degrees Celsius
Humidity: 0 to 90% non-condensing
Power Requirements
90 to 254 Volts AC (rms), 50/60Hz, 150 Watts per module.
Power Consumption
Power consumption of the Control Surface Modules is shown in the table below.
Individual Module Power Consumption
Module US (117V) Europe (230V) Japan (100V)
CM401 1.0A .5A 1.0A
CM402 1.0A .5A 1.0A
CM408 1.0A .5A 1.0A
• Inrush current : 25 Amps
• Fuse Rating: 5Amp Slo-Blo or Time Delay
