APPENDIX 1
Parts Lists
System 5 Leg Set
: Part# 946-07220-01
Item# Item Description Qty
726-06398-01 Leg-Left-Finished S5 1
726-06846-01 Leg-Left-Machined S5 1
726-06394-01 Panel-Weldment-Left Leg 1
726-06415-01 Keyboard Tray Assy 1
726-06493-01 Track-Keyboard Top S5 1
041-06290-00 10x32x1/4 Pan/Phil/Cz 8
726-06791-01 Track-Keyboard Base S5 1
000-06790-00 Glide-Keyboard S5 2
420-04065-00 Dpdt-20a Rocker 1
600-06387-00 Iec320/C14 Power Entry 1
600-00728-00 Line Filter/Am 1
110-05551-00 Coupler Rj45 Panel Mount 12
726-06419-01 Leg-Right-Finished S5 1
726-06847-01 Leg-Right-Machined S5 1
726-06826-01 Panel-Weldment-Right 1
042-05677-00 6-32x3/16 Flat/Phil/Clrznc 14
048-00929-00 6-32x3/8 Pan/Phil/Sem-Ext/Clr 4
046-06073-00 4-40x1/4l Pan/Phl/Clr Zinc 4
726-06405-01 Bracket-Rear Caster 2
06406-01 Bracket-Front Caster 2
726-06407-01 Caster-36mm 4
726-06838-01 Spacer-Left-S5 Cm 1
044-06686-00 5/16-18x.375 Bolt Socket 8
081-06417-00 #10 Flat Washer-Brass 2
726-06832-01 Ac Cover S5 2
000-06434-00 Leveling Pad-5/16-18 4
600-06991-00 Iec320/C13 Power Outlet 3
030-06993-01 Ca-Ac Line-S5 Frame 1
030-06994-01 Ca-Ac Neutral-S5 Frame 1
030-06995-01 Ca-Ac Gnd-S5 Frame 5
030-06996-01 Ca-Outlet Ac Line-S5 Frame 1
030-06997-01 Ca-Outlet Ac Neutral-S5 1
030-06998-01 Ca-Sw Line-S5 Frame 1
030-06999-01 Ca-Sw Neutral-S5 Frame 1
006-04969-00 Label-Universal Ground 1
049-00838-00 6-32 Kepnut/Ext/Clr Zinc 12
032-07207-00 Ca-Pwr/Iec/N-Usa/8ft/15a 1
030-07199-01 Ca-Door Support-S5 4
