S5 Control Surface/Frame Manual Page 39 Version 1.0 ©1999 Euphonix, Inc.
Knob value display
Displays the hex 0 through FF value of the knob being currently moved on an
intelligent display. This mode is useful for testing the CM401 spin knob.
Halo Test
This cycles through all the knob halo and center LEDs by turning one LED on at a
time on each key press.
Knob meter display
Shows the knob value as a bar on the meter board (fader daughter board).
Knob switch test
All the knobs halo orange LEDs light up while the knob center switch is pressed.
The Expansion port switches are also tested in this mode. Pressing one of the eight
switches will light up its LED for as long as the key is pressed.
Expansion port switch test
See the Knob switch test section.
