Euphonix System 5 Control Surface/Frame - Fader Test

S5 Control Surface/Frame Manual Page 40 Version 1.0 ©1999 Euphonix, Inc.
Fader Test
• All fader up
• All fader down
• Fader cycle test with speed control
• Fader echo test
• Touch Sense Test
• Backstop PFL switch test
• Fader Write value display
• Fader Read value display
• TFT backlight brightness test
This test is not accessible from the lower board.
CM401/CM408
All Fader Up
All Fader Down
Fader Cycle
Exit Test Key/Exit to
main
*
In
p
ut
D
y
n
EQ
Aux
Pan
Fader Echo
Strp SoloNum
Slv
PstCpyGrp
swapswapswapswap
On
All
Fader
Up
All
Fader
Down
Fader
Cycle
Exit
Test
CM402
Fader
Echo
