S5 Control Surface/Frame Manual Page 48 Version 1.0 ©1999 Euphonix, Inc.
Parts List (cont)
System 5 Frame Set, 6ft: Part# 946-06425-01
Item# Item Description Qty
726-06399-01 Beam-Box 6ft S5 2
726-06400-01 Clamp-Beam 4
726-06408-01 Beam-Back 6ft S5 1
726-06402-01 Plate-Back Beam 2
726-06403-01 Palm Rest-6ft S5 1
726-06404-01 Plate-Palm Beam 2
726-06411-01 Brace-Back 1
726-06686-01 Cover-Back 3ft 2
600-07223-00 Power Strip-Iec320-6pos 2
032-07147-00 Iec320 Jumper Cordset-0.5m 5
032-07148-00 Iec320 Jumper Cordset-1.0m 3
032-07149-00 Iec320 Jumper Cordset-1.5m 2
032-07150-00 Iec320 Jumper Cordset-2.5m 1
081-07193-00 3/8 Flat/Wash/Ss 8
936-07218-01 S5 Frame Bolt Kit 1
043-06688-00 5/16-18x3.5 Bolt Hex-Head-Zi 16
082-06689-00 5/16 Lockwasher 16
046-06401-00 5/16-18x2.25 Bolt Flat/Soc/Ss 8
046-06421-00 3/8-16x1.25l Buttonhd/Skt/Ss 8
081-07193-00 3/8 Flat/Wash/Ss 8
936-07241-01 S5 Rear Panel Bolt Kit 1
044-07236-00 ¼-20x3/8 B4cs 20
936-07239-01 S5 Tee Hardware Kit 1
000-06690-00 5/16-18x.375 Tee Nut/Cz 22
044-06686-00 5/16-18x.375 Bolt Socket Hd/Cz 22
936-07240-01 S5 Thumb Screw Kit 7
040-06833-00 10-32x3/8 Thumb\Washer Face 4
030-07394-01 Ca-Internal Ethernet/6ft 1
To Next Page
