Euphonix System 5 Control Surface/Frame - Alternate Usage #2

S5 Control Surface/Frame Manual Page 28 Version 1.0 ©1999 Euphonix, Inc.
Alternate Usage #2:
Another implementation combines the above two approaches – we have individual
Talkback enable buttons like in the Typical Usage, but we’ve added an ‘OMNI’ switch
that routes the Talkback signal to all four monitor outputs:
+5V
SW2A
2
3
1
4
SW4A
2
3
1
4
SW4B
LIGHTED SWITCH
6
5
SW3A
2
3
1
4
SW1B
LIGHTED SWITCH
6
5
SW2B
LIGHTED SWITCH
6
5
SW3B
LIGHTED SWITCH
6
5
SW1A
2
3
1
4
SW1A
2
3
1
4
D1
1N4148
D2
1N4148
D4
1N4148
D3
1N4148
PIN 5
PIN 18
PIN 19
PIN 15 PIN 1
PIN 16
PINS 3, 6, 9, 12, 13, 14, 17, 20, 23
(
PICK ANY 4
)
PIN 2
PIN 4
