S5 Control Surface/Frame Manual Page 9 Version 1.0 ©1999 Euphonix, Inc.
Dimensions and Weight
Height: 39.5 inches
Width: Frame size + 10”
Depth: 41 inches
Weight: Frame without modules
6ft Frame: 245lbs (111kg)
9ft Frame: 300lbs (136kg)
12ft Frame: 380lbs (172kg)
Approximately 14 inches of depth should be left behind the System 5 Control
Surface for cable connections.
