User Reference – Control Modules
Control Module Setup
Overview of Ethernet IP Address Allocation
Computers
Computer IP Address Pilot ID Frame ID Module ID
System Computer
192.168.0.1 N/A N/A
Digital Pilot
192.168.0.200 1 N/A 0
192.168.0.201 2 N/A 1
192.168.0.202 3 N/A 2
192.168.0.203 4 N/A 3
Interface Pilot
192.168.0.215 15 N/A 15
Control Modules
Module IP Address Frame ID Module ID
CM401
192.168.0.24 IL 15
CM402
192.168.0.25 IL 16
CM408
192.168.0.10 IL 1
192.168.0.11 IL 2
192.168.0.12 IL 3
192.168.0.13 IL 4
192.168.0.14 IL 5
192.168.0.15 IL 6
192.168.0.16 IL 7
192.168.0.17 IL 8
192.168.0.18 IL 9
