S5 Control Surface/Frame Manual Page 6 Version 1.0 ©1999 Euphonix, Inc.
Component Overview
Functional Description
The System 5 Console consists of a frame and leg assemblies which house a
configurable number of Control Modules that comprise the Control Surface. The
System 5 Control Surface is the digital control center for all the System 5 component
assemblies. The Control Surface communicates with the System 5 component
assemblies via Ethernet network connections. Control signals are transmitted to the
Euphonix EH224 EuCon Hub and distributed to the various System 5 component
assemblies. No audio passes through the Control Surface.
Available in 6 foot, 9 foot, and 12 foot frame widths, the System 5 Control Surface
is modular in construction. The number and variety of Control Modules are
configurable based on the specific needs of each facility. Control modules are 12
inches wide. Filler modules can be ordered in full or half width.
