APOLLO ‘at a glance’
ATX power supply connector COM4 RS485/RS422 serial port
PCI slot BIOS write protect/PCI power select
CD audio input
Video option
System and
CPU fans
LVDS display
interface
LCD backlight
connecto
r
System control
interface
3 stereo
audio jacks
Pin heade
r
to S/PDIF
optical output
IrDA connector
Front panel
interface
Primary IDE
interface
COM3/COM4
RS232 serial
ports
Firewire port 1
CompactFlash
socket
USB3/USB4
