Eurotech Apollo - Option Boards and Cables

Appendix C – TFT display interface cable
Issue G 133
Appendix C – TFT display interface cable
The following table shows the connection details for the AU Optronics 15" LCD flat panel
display G150XG01 used in the development kits:
APOLLO J17 DF-14H-20P-1.25H Panel signal name
1 NC NC
2 NC NC
3 1 +3.3V
4 2 +3.3V
5 3 Ground
6 4 Ground
7 5 Rin0-
8 8 Rin1-
9 6 Rin0+
10 9 Rin1+
11 7 Ground
12 10 Ground
13 11 Rin2-
14 NC NC
15 12 Rin2+
16 NC NC
17 13 Ground
18 NC NC
19 14 ClkIN-
20 NC NC
21 15 ClkIN+
22 NC NC
23 16 Ground
24 19 Ground
25-40 NC NC
