ISIS user manual
Issue G
134
The following table shows the connection details for the TDK CXA-P1612-VJL backlight
inverter cable. This configuration allows for PWM based brightness control from the
APOLLO board. See J15 – Backlight connector
, page 42, and LCD backlight connector,
page 96,
for further details.
APOLLO J15 51021-0500 housing
1 1
2 2
3 NC
4 3
5 5
6 NC
Pin 4 of the 5 way housing is not used and
should be removed.
