Jumpers and connectors
Issue G 31
Connectors
There are 34 connectors on the APOLLO that let you connect external devices such as
keyboards, floppy disk drives, hard disk drives, printers etc.
Connector Function See …
J1 Audio Line Out. Page 32
.
J2 Audio Line In. Page 32.
J3 Audio Mic In. Page 32
.
J4A IEEE1394 port 0. Page 34
.
J4B, J4C USB ports 1 to 2. Page 34
.
J5A Primary LAN. Page 35
.
J5B Secondary LAN. Page 35
.
J6A VGA connector. Page 36
.
J6B Keyboard. Page 36
.
J6C Mouse. Page 36
.
J7A Parallel port (LPT1). Page 37
.
J7B, J7C Serial ports 1 to 2. Page 38
.
J8 S/PDIF output. Page 38
.
J9 CD audio input. Page 38
.
J10 System fan. Page 39
.
J11 CPU fan. Page 39
.
J12 ATX power connector. Page 39
.
J13 PCI slot. Page 40
.
J14 System control interface. Page 41
.
J15 LCD backlight interface. Page 42
.
J16 Video option and USB ports 5/6
connector.
Page 42
.
J17 LVDS display interface. Page 44
.
continued…
