J13 – PCI connector
32-bit card edge connector. Three grant/request lines routed.
Connector: 120-way PCI card edge connector (5V 32-bit 33MHz PCI socket).
Pin Side B Side A Pin Side B Side A
1 -12V /TRST 32 AD17 AD16
2 TCK (GND) +12V 33 /CBE2 +3.3V
3 Ground TMS (+5V) 34 Ground /FRAME
4 No Connect TDI (+5V) 35 /IRDY Ground
5 +5V +5V 36 +3.3V /TRDY
6 +5V /INTE 37 /DEVSEL Ground
7 /INTF /INTG 38 Ground /STOP
8 /INTH +5V 39 /LOCK +3.3V
9 No Connect /REQ4 40 /PERR SMB CLK
10 / REQ3 +5V(I/O) 41 +3.3V SMB DATA
11 No Connect /GNT3 42 /SERR Ground
12 Ground Ground 43 +3.3V PAR
13 Ground Ground 44 /CBE1 AD15
14 No Connect VAUX (/GNT4) 45 AD14 +3.3V
15 Ground /RST 46 Ground AD13
16 CLK +5V(I/O) 47 AD12 AD11
17 Ground /GNT1 48 AD10 Ground
18 /REQ1 Ground 49 Ground AD09
19 +5V(I/O) /PME 50 Key Key
20 AD31 AD30 51 Key Key
21 AD29 +3.3V 52 AD08 /CBE0
22 Ground AD28 53 AD07 +3.3V
23 AD27 AD26 54 +3.3V AD06
24 AD25 Ground 55 AD05 AD04
25 +3.3V AD24 56 AD03 Ground
26 /CBE3 IDSEL (AD27) 57 Ground AD02
continued…
