EVCO S.p.A. c-pro 3 nano CHIL | Application manual ver. 1.0 | Code 144CP3NCHE104
page 26 of 90
calibration circuit 2
PM87
Single pressure sensor calibration
circuit 1
0.0 -20.0 20.0 Bar MA-C
PM88
Single pressure sensor calibration
circuit 2
0.0 -20.0 20.0 Bar MA-C
PSd2
Change the password at maintenance
operator level.
0 -999 9999 MA-F
Level
3
INSTALLATION MENU
COMPRESSORS
PC01
Type of rotation used for compressor
management:
0: FIFO
1: LIFO
2: FIFO + hours
3: LIFO + hours
0 0 3 IS-C
PC02
Enable compressors in the two
circuits:
0: Balancing of the circuit
1: Saturation of the circuit
0 0 1 IS-C Only on the double circuits
PC04
Min. period during which the
compressor has to stay on, even if
switch-off has been requested.
20 0 999 Sec. IS-C
PC05
Min. period during which the
compressor has to stay off, even if
switch-on has been requested.
120 0 999 Sec. IS-C
PC06
Min. period that must elapse between
two start-ups of the same
compressor.
360 0 999 Sec. IS-C
PC07
Min. period that must elapse between
two start-ups of two different
compressors.
360 0 999 Sec. IS-C
PC08
Min. period that must elapse between
the shutdowns of two different
compressors.
180 0 999 Sec. IS-C
PC09
Max. number of start-ups per each
hour (only for adaptive control).
8 4 12 IS-C
PC10
Number of compressors per circuit
that will be forced in the event of
regulation probe alarm.
1 0 PG03 IS-C
REGULATION
PC11
Set the type of control for compressor
management:
0: Lateral band
1: Zero energy band
1 0 1 IS-R
PC12
Proportional band for compressor
lateral band control
2.5 1.0 20.0 °C IS-R
PC14
Value of the zone for compressor
neutral zone control
3.0 PC15 PC16 °C IS-R
PC15
Min. value of the compressor zero
energy band
1.0 0.1 10.0 °C IS-R
PC16
Max. value of the compressor zero
energy band
5.0 0.1 10.0 °C IS-R
PC17 Enable/release time for the next step 20 0 999 Sec. IS-R
