EVCO S.p.A. c-pro 3 nano CHIL | Application manual ver. 1.0 | Code 144CP3NCHE104
page 38 of 90
PV82 Min. superheating circuit 1 2.0 1.0 25.0 °K CO-V
PV83 Max. discharge superheating circuit 1 35.0 0.0 50.0 °K CO-V
PV84 Min. discharge superheating circuit 1 5.0 0.0 50.0 °K CO-V
EVDRIVE03 circuit 2
PV41 SH set-point (1) 6.0 3.0 25.0 K CO-V
PV42 LoSH set-point (1) 2.0 1.0 3.0 K CO-V
PV43 HiSH set-point (1) 15.0 10.0 40.0 K CO-V
PV44 LOP set-point (1) -40.0 -40.0 40.0 K CO-V
PV45 MOP set-point (1) 40.0 -40.0 40.0 K CO-V
PV46 PID – proportional band (1) 7.0 1.0 100.0 K CO-V
PV47 PID – integral time (1) 120 0 999 sec CO-V
PV48 PID – derivative time (1) 120 0 999 sec CO-V
PV49 Start-up delay (1) 5 1 255 sec CO-V
PV50 Start-up position (1) 50.00 00:00 100.00 % CO-V
PV51 SH set-point (2) 6.0 3.0 25.0 K CO-V
PV52 LoSH set-point (2) 2.0 1.0 3.0 K CO-V
PV53 HiSH set-point (2) 15.0 10.0 40.0 K CO-V
PV54 LOP set-point (2) -40.0 -40.0 40.0 K CO-V
PV55 MOP set-point (2) 40.0 -40.0 40.0 K CO-V
PV56 PID – proportional band (2) 7.0 1.0 100.0 K CO-V
PV57 PID – integral time (2) 120 0 999 sec CO-V
PV58 PID – derivative time (2) 120 0 999 sec CO-V
PV59 Start-up delay (2) 5 1 255 sec CO-V
PV60 Start-up position (2) 50.00 00:00 100.00 % CO-V
PV61 Stabilisation period 0 0 255 sec CO-V
PV62 Stabilisation position 100.00 0.00 100.00 % CO-V
PV63
Operating mode:
0= SH algo
1= Manual
0 0 1 CO-V
PV64 Manual position 0.00 0.00 100.00 % CO-V
PV65
SH parameter setpoint:
0= set1
1= set2
0 0 1 CO-V
PV66
Relay function:
0= Disabled
1= Enabled: any alarm
2= Enabled: probe error
3= LoSH alarm
4= MOP alarm
5= valve alarm
6= solenoid valve
7= solenoid valve + alarms
8= resynchronisation
6 0 8 CO-V
PV67
Probe type 3:
0= NTC
1= PT1000
0 0 1 CO-V
PV68
Probe type 4:
0= 4..20mA (0.5 – 8)
1= 4..20mA (0 – 30)
2= 0-5V (0 – 7)
3= 0-5V (0 – 25)
4= 0-5V (0 – 60)
5= scaling
0 0 1 CO-V
