EVCO S.p.A. c-pro 3 nano CHIL | Application manual ver. 1.0 | Code 144CP3NCHE104
page 37 of 90
1= Manual
PV24 Manual position 00:00 00:00 100.00 % CO-V
PV25
SH parameter setpoint:
0= set1
1= set2
0 0 1 CO-V
PV26
Relay function:
0= Disabled
1= Enabled: any alarm
2= Enabled: probe error
3= LoSH alarm
4= MOP alarm
5= valve alarm
6= solenoid valve
7= solenoid valve + alarms
8= resynchronisation
6 0 8 CO-V
PV27
Probe type 3:
0= NTC
1= PT1000
0 0 1 CO-V
PV28
Probe type 4:
0= 4..20mA (0.5 – 8)
1= 4..20mA (0 – 30)
2= 0-5V (0 – 7)
3= 0-5V (0 – 25)
4= 0-5V (0 – 60)
5= scaling
0 0 1 CO-V
PV29
Probe type 1:
1= PTC
2= NTC
3= 0..20mA
4= 4..20mA
5= 0-5V
6= 0-10V
7= PT1000
8= NTC K2
9= NTC K3
5 1 9 CO-V
PV30
Probe type 2:
1= PTC
2= NTC
3= 0..20mA
4= 4..20mA
5= 0-5V
6= 0-10V
7= PT1000
8= NTC K2
9= NTC K3
2 1 9 CO-V
PV31 Offset Ts 0.0 -10.0 10.0 K CO-V
PV32 Offset Te 0.0 -10.0 10.0 K CO-V
PV34 Relay logic N.O. (0) N.O. (0) N.C. (1) CO-V
PV35 DI1 Logic N.O. (0) N.O. (0) N.C. (1) CO-V
PV36 DI2 Logic N.O. (0) N.O. (0) N.C. (1) CO-V
PV37 DI3 Logic N.O. (0) N.O. (0) N.C. (1) CO-V
PV80
Enable superheating modulating
setpoint circuit 1
Yes (1) No (0) Yes (1) CO-V
PV81 Max. superheating circuit 1 15.0 3.0 25.0 °K CO-V
