c-pro 3 nano CHIL | Application manual ver. 1.0 | Code 144CP3NCHE104
page 36 of 90
HC04 0
HC05
HC06
HC07
HC08
They set which analogue resources to
connect to the analogue outputs
1, 2, 3, 4 of the expansion
0 0 9
CO-
HW
HC09
HC10
Set which analogue resources to
connect to the analogue outputs 5, 6
of the expansion
0 0 6
CO-
HW
HCF1
Set the frequency of operation of the
free-cooling fan’s PWM
1000 10 2000 Hz
CO-
HW
HCF2
Set the frequency of operation of the
PWM of the fan of circuit 1
1000 10 2000 Hz
CO-
HW
HCF3
Set the frequency of operation of the
PWM of the fan of circuit 2
1000 10 2000 Hz
CO-
HW
HD01
…
HD07
Set which digital resources to link to
the controller's digital outputs
2
12
14
26
20
22
40
0 48
CO-
HW
See Table
Config. DO
HD08
…
HD16
Set which digital resources to link to
the expansion's digital outputs
0 0 48
CO-
HW
ELECTRONIC VALVE MODULES
EVDRIVE03 circuit 1
PV01 SH set-point (1) 6.0 3.0 25.0 K CO-V
PV02 LoSH set-point (1) 2.0 1.0 3.0 K CO-V
PV03 HiSH set-point (1) 15.0 10.0 40.0 K CO-V
PV04 LOP set-point (1) -40.0 -40.0 40.0 K CO-V
PV05 MOP set-point (1) 40.0 -40.0 40.0 K CO-V
PV06 PID – proportional band (1) 7.0 1.0 100.0 K CO-V
PV07 PID – integral time (1) 120 0 999 sec CO-V
PV08 PID – derivative time (1) 120 0 999 sec CO-V
PV09 Start-up delay (1) 5 1 255 sec CO-V
PV10 Start-up position (1) 50.00 00:00 100.00 % CO-V
PV11 SH set-point (2) 6.0 3.0 25.0 K CO-V
PV12 LoSH set-point (2) 2.0 1.0 3.0 K CO-V
PV13 HiSH set-point (2) 15.0 10.0 40.0 K CO-V
PV14 LOP set-point (2) -40.0 -40.0 40.0 K CO-V
PV15 MOP set-point (2) 40.0 -40.0 40.0 K CO-V
PV16 PID – proportional band (2) 7.0 1.0 100.0 K CO-V
PV17 PID – integral time (2) 120 0 999 sec CO-V
PV18 PID – derivative time (2) 120 0 999 sec CO-V
PV19 Start-up delay (2) 5 1 255 sec CO-V
PV20 Start-up position (2) 50.00 00:00 100.00 % CO-V
PV21 Stabilisation period 0 0 255 sec CO-V
PV22 Stabilisation position 100.00 00:00 100.00 % CO-V
PV23
Operating mode:
0= SH algo
0 0 1 CO-V
