User Guide System Mode
42
To use Learn Mode, press the Left Footswitch again. In LEARN mode, the Prg. No. will be
automatically set when a MIDI Program Change message is received. Pressing the Left
Footswitch exits LEARN mode.
Press the Right Footswitch to select the Preset field (indicated by the flashing Right Footswitch
LED) and turn the Encoder to select the Preset.
To map another Prg No. to another Preset, simply press the Left Footswitch again to select
the desired Prg No. and then the Right Footswitch to map it to the desired Preset.
Default map: Prg No. 0-99 map to the 100 Presets (1-100).
As well as using MIDI program change to load a preset, it can also be programmed to directly
control the unit’s BYPASS setting. When the Right Footswitch LED is flashing, turn the
Encoder counter-clockwise to select one of the following:
OFF Unassigned
BYPASS BYPass the unit
ACTIVE Make the unit Active, i.e., not bypassed.
TOGGLE Toggle the between bypass and active.
Press the Middle Footswitch once to back-up one level to MIDI menu.
Press the Middle Footswitch twice to go to the top level System menu.
[XMT MAP] – Create a MIDI Program Change Transmit Map
In Preset Mode, when the Left Footswitch loads a Preset, a MIDI Program Change message
can be transmitted from the MIDI Out jack or USB to control an external device - e.g., another
Eventide Stompbox, an Eventide Eclipse, an Eventide H8000FW, etc.
To Create a MIDI Program Change transmit map, Press the Encoder to access the MIDI
transmit map for editing.
The Left field displays the Preset number (1 to 100). The right field displays either OFF or the
Prg No. (0-127). Default map: Prg No. 0-99 map to the 100 Presets.
Press the Left Footswitch to select Preset field (indicated by the flashing Left Footswitch LED),
turn the Encoder to select the Preset.
Press the Right Footswitch to select Prg No. field (indicated by the flashing Right Footswitch
LED), turn the Encoder to select the corresponding number.
Note: MIDI Program Change Transmit must be enabled in order for to transmit
Program Change messages. MIDI Program Change Transmit is turned ON or OFF in the MIDI
menu. Default is OFF.
Note: When a Preset is recalled with a MIDI program change message, MIDI Program
Change messages are not generated.
Press the Middle Footswitch once to back-up one level to MIDI menu.
Press the Middle Footswitch twice to go to top level System menu.
