User Guide System Mode
43
[CTL XMT] – MIDI Continuous Controller Transmit Enable (ON, OFF)
Press the Encoder to select. Turn Encoder to set MIDI Continuous Controller transmit ON or
OFF. This setting determines if Parameter Knobs transmit MIDI control messages.
Press the Middle Footswitch once to back-up one level to MIDI menu.
Press the Middle Footswitch twice to go to top level System menu.
[PGM XMT] – MIDI Program Change Transmit Enable (ON, OFF)
Press the Encoder to select. Turn Encoder to set MIDI Program Change transmit ON or OFF.
If ON, a MIDI Program change message is transmitted whenever a Footswitch is pressed for
Preset load.
Press the Middle Footswitch once to back-up one level to MIDI menu.
Press the Middle Footswitch twice to go to top level System menu.
[SYS ID] – MIDI SysEx ID (1-16)
Press the Encoder to select. Turn Encoder to choose the MIDI SysEx ID for Backup and Restore
of Presets and System settings.
Press the Middle Footswitch once to back-up one level to MIDI menu.
Press the Middle Footswitch twice to go to the top level System menu.
[OUTPUT] – MIDI Transmit/Thru Select (XMT, THRU)
Press the Encoder to select. Turn Encoder to select whether ’s MIDI Output transmits
(XMT) MIDI data or passes incoming MIDI data thru .
Note: if OUTPUT is set to THRU, none of ’s MIDI Transmit functions will be operative.
Press the Middle Footswitch once to back-up one level to MIDI menu.
Press the Middle Footswitch twice to go to the top level System menu.
[DUMP] – Dump Select (ALL, CURRENT, PRESETS, SYSTEM)
Press the Encoder to select. Turn Encoder to set what is being backed up via SysEx Dump or
Dump Request.
If ALL is selected, all saved Presets and System settings are dumped.
If CURRENT is selected, only the currently loaded Preset is dumped.
If PRESETS is selected, the currently selected range of Presets is dumped. If you have not
limited the Preset Range, all 100 Presets will be dumped.
If SYSTEM is selected, all System Mode settings are dumped.
Press the Middle Footswitch once to back-up one level to MIDI menu.
Press the Middle Footswitch twice to go to the top level System menu.
[MIDICLK IN] – MIDI Input Clock Enable (ON, OFF)
Press the Encoder to select. Turn Encoder to set MIDI Clock Receive ON or OFF. If ON, MIDI
Clock is used as a Tempo source.
