Ever Pharma D-mine Pump - Technical Data

146
147
10
LOT
REF
SN
IP 42
SYMBOLS ON THE PRODUCT
10.2
TECHNICAL DATA
Dimensions
(with reservoir,
without adapter)
Length 114.3 mm
Width 61.4 mm
Depth 29.9 mm
Weight
Pump 140 g
Reservoir empty 22 g
Temperature
In operation
(including rechargeable battery charging)
+5 to +40 ºC
Storage (including transport) ‑25 to +70 ºC
Air humidity
In operation 15to 90 % RH
Storage up to 93 % RH
Atmospheric pressure
In operation 700to 1060 hPa
Storage n/a hPa
Power supply
Rechargeable battery
Lithium polymer
CP5/26/54
3.7
650
2.4
V
mAh
Wh
Docking station
100‑240
50‑60
0.6
V
Hz
A
Pump mechanism
Micro‑piston pump 10μl/stroke
Device adjustment time
Warm‑up time 30 min
Cooling time 30 min
Marking for conformity with
standards in the USA and Canada
Conformity marking in accordance
with the European Medical Device
Directive and number of the
notified body
Do not discard with
household waste
Batch number
Protect from moisture
Protect from heat
and sunlight
Temperature limit
For single use only
Do not use if packaging is
damaged
Sterilisation by irradiation
Use by
Pyrogen‑free
Item number
Serial number
Manufacturer
Date of manufacture
Equipment type BF according to
standard IEC 60601‑1.
Protection against electric shock
Observe warnings in the
instructions for use.
Follow instructions for use.
Symbol for protection against
particles and water
in accordance with IEC 60529
MEDICAL —
CARDIO, VASCULAR AND PULMONARY
EQUIPMENT
AS TO ELECTRICAL SHOCK, FIRE AND
MECHANICAL HAZARDS ONLY
IN ACCORDANCE WITH
ANSI/AAMI ES60601‑1 (2005) + AMD 1 (2012)
CAN/CSA‑C22.2 No. 60601‑1 (2014)
IEC 60601‑1‑6 (2013)
ANSI/AAMI HA60601‑1‑11 (2015)
IEC 60601‑2‑24 (2012)
E363201
UR classification marking
