STEP 6
1. Attach the Slide Rail (2) to the Main Frame (1). Insert the Rail Shaft (46) and secure using
2 Bolts (81) and 2 Washers (44) with the provided Allen Wrench (97).
2. Insert the Ball Head Pin (65) into the lower slot on the Main Frame (1) & Slide Rail (2). Lift
center of frame to help line up locking pin holes. This locks the rower in the unfolded position
and can be removed to fold the rower up.
65
1
2
44
81
46
44
81
#81 M8*20 2pcs
6 S F
#44 OD20*ID8.5*1.5 2pcs
#46 Ø16*110 1pc
#65 Ø12 1pc
