STEP 7
1. Slide the Outer Hexagonal Screw (50) through the Pedal (12), then through a Pedal
Bushing (64) before attaching and securing to the Main Frame (1) using the Spanner (98).
A second Outer Hexagonal Screw (50) is directly secured onto the Main Frame (1) in the
lower half of the Pedal (12).
2. Repeat for the other Pedal (12).
64
50
50
64
1
#98 1pc
#50 M12*160 4pcs
#64 Ø18*Ø13*26 2pcs
12
12
