Model 5600ACO2 Automatic Changeover Unit
Features:
• Relay switches for all the system critical outputs from two 5600MSC units
• 6 video/sync outputs
• 4 HD SDI test signal outputs
• 4 SDI test signal outputs
• 1 Analog video test signal output
• 10MHz frequency reference or Word Clock output
• Balanced and unbalanced DARS and AES outputs
• Balanced analog audio output
• Linear time code outputs
• Automatic changeover is a voting system based on which source has the most valid signals and
that the good signals on the present master are also on the backup.
• Three front panel switches select automatic, front panel or GPI activation of changeover
• Front panel switches are recessed to prevent accidental operation
• 42 Front panel status LEDs show the health of each of the inputs
• 14 Front panel status LEDs show the operational modes of the changeover
• Redundant power supply standard
• VistaLINK
®
capable offering remote monitoring and configuration capabilities via SNMP using the
model 9000NCP Network Control Panel or Evertz VistaLINK
®
PRO or other third party SNMP
manager software.
Signal Type Inputs Outputs
Sync 12 BNC 6 BNC
Word Clock / 10 MHz 2 BNC 1 BNC
DARS / AES 4 BNC 2 BNC
LTC 2 DB9 2 Male XLR
GPIO 2 DB9 Terminal Strip
Balanced DARS / AES / Analog audio 2 Terminal Strips Terminal Strip
HD SDI 8 BNC 4 BNC
SD SDI 8 BNC 4 BNC
Analog Video TG 2 BNC 1 BNC
Page 1-2
Revision 1.3 OVERVIEW
