evertz 5600ACO2 - Figure 1-2: Redundant Master Clock;Spg with Auto-Changeover System Diagram

Model 5600ACO2 Automatic Changeover Unit
5600MSC
5600ACO2
5600MSC
6 Sync
/Black
4 SDI
Test Signals
4 HD SDI
Test Signals
2 LTC
1 Analog TG
DARS/AES/
Analog Audio
Word Clock/
10 MHz Ref
GPIO
Dual
Power
Supply
Figure 1-2: Redundant Master Clock/SPG with Auto-Changeover System Diagram
Page 1-4
Revision 1.3 OVERVIEW
