Model 5600ACO2 Automatic Changeover Unit
2.1.5. Power Connections
LINE: The 5600ACO2 has redundant universal power supplies operating on 100 to 240VAC,
60 or 50 Hz.
2.2. MOUNTING
The 5600ACO2 is equipped with rack mounting angles and fits into a standard 19 inch by 1 3/4 inch
(483 mm x 45 mm) rack space. The mounting angles may be removed if rack mounting is not desired.
2.3. POWER REQUIREMENTS
Power requirements are 100 to 240 volts AC at 50 or 60 Hz. The 5600ACO has redundant universal
power supplies that automatically sense the input voltage. Power should be applied by connecting a 3-
wire grounding type power supply cord to each of the power entry modules on the rear panel. The
power cord should be minimum 18 AWG wire size; type SVT marked VW-1, maximum 2.5 m in length.
The power entry modules combine a standard power inlet connector, two 5 x 20 mm fuse holders and
an EMI line filter. See section 4.4.1 for information on changing the fuses.
CAUTION - To reduce the risk of electric shock, grounding of the centre pin
of the mains plug must be maintained
Make sure that both power cords are disconnected before opening the top
cover of the unit.
2.4. 5600MSC CONNECTIONS
The 5600MSC unit connected to the A inputs of the 5600ACO2 will be called Master A. The 5600MSC
unit connected to the B inputs of the 5600ACO2 will be called Master B.
2.4.1. Sync Outputs
Connect the six Sync outputs of the Master A 5600MSC unit to the A Sync inputs of the 5600ACO2.
Connect the six Sync outputs of the Master B 5600MSC unit to the B Sync inputs of the 5600ACO2.
Connect the Sync outputs of the 5600ACO2 to your plant distribution amplifier system.
Page 2-4
Revision 1.3 INSTALLATION
