Model 5600ACO2 Automatic Changeover Unit
4.3.3. Voting Control
3) Voting Control – set which input channel pair is included in the voting pool. Note that item 25 is the
global enable for items 1 through 24. If 25 is set to Yes, then voting will be determined by the settings
of items 1 through 24, and the settings of DIP switches 4, 5 and 7 are ignored. If it is set to NO, then all
channel pairs are included except HD-SDI and SD-SDI, which are determined by the DIP switch 7
setting. When set to NO the settings of DIP switches 3 and 4 also apply. See section 3.3.7.
---- 5600ACO2 Voting Control ----
(1) Sync 1
(2) Sync 2
(3) Sync 3
(4) Sync 4
(5) Sync 5
(6) Sync 6
(7) LTC 1
(8) LTC 2
(9) GPO 1
(10) GPO 2
(11) Ten MHz
(12) ATG
(13) Balanced AES
(14) Unbalanced AES
(15) Balanced DARS
(16) Unbalanced DARS
(17) SD Black 1
(18) SD Black 2
(19) SD Test Gen 1
(20) SD Test Gen 2
(21) HD Black 1
(22) HD Black 2
(23) HD Test Gen 1
(24) HD Test Gen 2
(25) Enable channel voting.
(S) Save and exit
(X) Exit without saving
