Model 5600ACO2 Automatic Changeover Unit
Connect a straight through serial cable (supplied with the 5600ACO2) between the COM serial port on
the rear panel and a PC’s serial port. Start HyperTerminal (or an equivalent terminal program) on the
PC and configure the port settings of the terminal program as follows:
Baud
57600
Data bits
8
Parity
None
Stop bits
2
Flow Control
None
Once the unit is powered-up, the HyperTerminal connection displays boot-up status information and
once completed, ends with the “Status Message” as shown below:
Initialization Completed – 5600ACO2 Running
Press the <Enter> key to see the main Menu. In the Main Menu, the following options are present for
module configuration.
"
Once changes completed and saved, the 5600ACO2 should be power-cycled for
the changes to take effect.
---------------------------------------------
| Main Menu |
| (5600ACO2 1.8.1 b19029) | < 5600ACO2 Firmware Version Information
---------------------------------------------
(1) Network Configuration
(2) SNMP Configuration
(3) Voting Control
(4) Show status
TECHNICAL DESCRIPTION
Revision 1.3 Page 4-5
