51 Fuel injector circuit #1 OPEN LED 2: ON (Running) - 2 seconds
Check injector/circuit resistance—2 to 3
Ω @ 72°F (22°C).
52 Fuel injector circuit #2 OPEN LED 2: ON (Running) - 2 seconds
53 Fuel injector circuit #3 OPEN LED 2: ON (Running) - 2 seconds
57 High RPM with low TPS setting
33
LED 3: FLASHING
CHECK ENGINE
(FLASHING)
10 seconds
TPS < 5% and RPM > 3000. Engine SHUTDOWN. Will NOT restart until code has been cleared. The problem could be caused by
uncontrolled fuel entering the engine. DO NOT attempt to start the outboard until the problem has been found and repaired.
58 Operating temperature not reached LED 3: OFF (Cranking) / ON (Running) - 10 minutes
Engine temperature < 104° F (40° C) with engine speed < 2300 RPM.
Check thermostat and pressure relief valve.
61 Fuel injector circuit #1 SHORTED LED 2: ON (Running) - 8 seconds
Check injector/circuit resistance—2 to 3
Ω @ 72°F (22°C).
62 Fuel injector circuit #2 SHORTED LED 2: ON (Running) - 8 seconds
63 Fuel injector circuit #3 SHORTED LED 2: ON (Running) - 8 seconds
81 Ignition timing circuit #1 OPEN LED 2: ON (Running) - 10 instances
EMM counts failed ignition events. Check wiring. Test with known good ignition coil.82 Ignition timing circuit #2 OPEN LED 2: ON (Running) - 10 instances
83 Ignition timing circuit #3 OPEN LED 2: ON (Running) - 10 instances
90 Water injection solenoid SHORTED LED 2: ON (Running) - 8 seconds Check circuit resistance—295
Ω ± 20 @ 77°F (25°C).
91 Fuel pump circuit OPEN LED 2: ON (Running) - 8 seconds
Check pump/circuit resistance—2 to 3
Ω @ 77°F (25°C).
93 Water injection solenoid OPEN LED 2: ON (Running) - 8 seconds Check circuit resistance—295
Ω ± 20 @ 77°F (25°C).
94 Fuel pump circuit SHORTED LED 2: ON (Running) - 2 seconds
Check pump/circuit resistance—2 to 3
Ω @ 77°F (25°C).
101 Ignition timing circuit #1 SHORTED LED 2: ON (Running) - 20 instances
EMM counts failed ignition events. Check wiring. Test with known good ignition coil.102 Ignition timing circuit #2 SHORTED LED 2: ON (Running) - 20 instances
103 Ignition timing circuit #3 SHORTED LED 2: ON (Running) - 20 instances
117 Critical LOW OIL detected
33
LED 4: ON (Running) NO OIL
4800 Pulses (2 Cyl)
6000 Pulses (3 Cyl)
EMM counts oil pump pulses after LOW OIL switch closes. Engine limited to 1200 RPM.
Stop outboard and add oil to tank. Warning resets after three oil pump pulses.
NOTE: Always note service codes before clearing codes. Clear stored codes using diagnostic software. Clearing some codes requires turning EMM “OFF” and then “ON” again.
CODE
EMM CIRCUIT/SENSOR
INTERNAL
SENSOR
S.A.F.E
SHUT
DOWN
EMM LED DISPLAY
DASHBOARD
GAUGE WARNING
DISPLAY
TIME TO
ACTIVATE
SENSOR: CIRCUIT VOLTAGE / RESISTANCE (Ω) / INFORMATION
page 2
Rev 09/07
