Evolution Digital
EVO-SUP-DMS2002HD-U-001-v1r0 Page 60
Figure 36 Diagnostic Menu – Virtual Channel Map
6.9 Received Messages
The Received Messages screen displays the count of the various messages ingested by the DTA. This screen will
provide useful information indicating if the DTA is receiving data on the Network PID as well as messages from the
headend. Table 19 defines the parameters displayed in the Received Messages screen.
Table 19 Received Messages Screen Parameters
Parameter
Description
CDS
Count of the number of CDS tables
received by the DTA.
MMS
Count of the number of MMS tables
received by the DTA.
SNS
Count of the number of SNS tables
received by the DTA.
