Evolution Digital HD uDTA - Table 5 Pending Initialization Mode Properties

Evolution Digital
EVO-SUP-DMS2002HD-U-001-v1r0 Page 20
Table 5 Pending Initialization Mode Properties
Mode activities
Verifying CA parameters
found in hunt mode,
monitoring network PID
and EMM PID
Valid Mode Transition(s)
Common Download, Boot,
Normal Operations
LED status
Two blinks, repeated
continuously
A/V Decode
None
Diagnostics
Available
IR Input
Available
In-band Message
Processing
Network and EMM PIDs
Once the DTA is in Pending Init Mode, the DTA can be sent activation and configuration messages. The DTA
will remain in Pending Init Mode until it is Activated with a proper configuration message from the headend and has
downloaded the full channel map it is assigned to. Figure 7 shows the DTA Status diagnostic screen while the DTA
is in Pending Initialization Mode.
