3. Description V10k automatic
10
EN
3.4 Technical Data
Chlorinator with positioner on mounting plate
The chlorinator can be equipped with different flowmeter tubes and V-notches. By changing
these parts and if necessary the injector, the dosing range can be changed.
with short flowmeter (5") or long flowmeter (10") part no. W3T159301
Regulating range of the V notch *) refer to the shipping documents
Display range of the flowmeter *) refer to the shipping documents
Flowmeter Accuracy class 4
Operating temperature 0°C to +50°C
Operating vacuum approx. 200 mbar
Operating pressure of the 1“ injectors max. 21 bar g up to 20°C,
max. 16 bar g up to 30°C,
max. 12 bar g up to 40°C,
max. 8 bar g up to 50°C
Operating pressure of the ¾“ injectors max. 16 bar g up to 20°C,
max. 13 bar g up to 30°C,
max. 10 bar g up to 40°C,
max. 5,9 bar g up to 50°C
Noise < 70 dB (A)
Positioner 230 V, 50 Hz 19 mA,
positioning time approx. 80 sec.
potentiometer 1 kOhm ± 10%
Positioner 115 V, 60 Hz 46 mA,
positioning time approx. 66 sec.
potentiometer 1 kOhm ± 10%
Dimensions incl. mounting plate (W x H x D)
V10k with positioner 369 x 880 x 185, weight approx. 15 kg
