4. Installation V10k automatic
14
EN
Max. tube/pipe length from V10k to injector
4.5 Electric connection
4.5.1 Connecting solenoid valve / boo‐
ster pump
refer to Typical Installations in chapter 7.1
A booster pump is necessary if the operation
water pressure is too low.
1 Lock the booster pump to the flow in the
main water line (e.g. by using a flow sen-
sor)
When using a solenoid valve in the main water
line:
1 Lock the solenoid valve to the flow in the
main water line (e.g. by using a flow sen-
sor)
4.5.2 Connecting the positioner
The positioner can be connected to a Evoqua
control unit, other controls or a remote cont-
rol panel.
Connect the positioner according to wiring
diagram 30-E-7693 (see chapter 8 and the ins-
tructions of the control).
• CLOSE/DEC: connecting rod moves out,
chlorinator flow decreases,
• OPEN/INC: connecting rod moves in, chlo-
rinator flow increases.
The positioner is supplied with three cable
glands and two plug screws. Insert as applica-
ble. The following bores are provided:
• for 230 V positioners: ø 20.5 mm
4000 - 9 m 28 m 91 m 364 m 1042 m
6000 - 5 m 15 m 43 m 145 m 479 m
8000 - 2 m 8 m 25 m 98 m 294 m
10000 - 1, 5 m 5 m 16 m 73 m 206 m
Feed of
Cl2, SO2
in g/h
PE hose
6,35 mm
(1/4“)
PE hose
9,5 mm
(3/8“)
PE hose
12 mm
(1/2“)
PVC pipe
DN 15
PVC pipe
DN 20
PVC pipe
DN 25
Feed of
Cl2, SO2
in g/h
PE hose 6,35
mm (1/4“)
PE hose 9,5
mm (3/8“)
PE hose 12
mm (1/2“)
PVC pipe
DN15
PVC pipe
DN20
PVC pipe
DN25
200 415 m 2000 m - - - -
400 243 m 1115 m 2515 m - - -
1000 40 m 146 m 1420 m 2850 m - -
2000 10 m 55 m 178 m 532 m 1748 m -
3000 5 m 26 m 88 m 298 m 1010 m 3088 m
4000 - 15 m 46 m 151 m 606 m 1736 m
6000 - 7 m 25 m 71 m 240 m 798 m
8000 - 4 m 13 m 40 m 163 m 490 m
10000 - 2, 5 m 8 m 26 m 121 m 343 m
WARNING
To avoid personal injury by electrical energy
only authorized and qualified electrical per-
sonnel may carry out works on electrical
parts of the system.
Connect the control cabinet according to the
wiring diagrams and the national and local
codes. Before opening positioner or electric
control unit, ensure that mains supply is
switched off.
WARNING
Danger of over-chlorination!
The water through the injector may flow
only when the water in the main water line
flows.
