V10k automatic 6. Maintenance
35
EN
6.5.11 Maintenance kit W3T167032
for Injector 1” anti‐syphon (W3T171368), 5 years
6.5.12 Set of gaskets W3T167496 for Injector ¾” (W3T171369)
Pos. Part No. Description Quant.
0001 W3T159661 Valve seat 5
0002 W3T161480 o-ring d 13 x 2 5
0003 W3T172921 o-ring d 10 x 4 2
0004 W3T170187 Valve seat 2
0005 W3T172822 o-ring d 15,54 x 2,62 10
0006 W3T172899 o-ring d 23,47 x 2,62 5
0007 W3T161113 Spring TANTALOY 61, D24 1
0008 W3T159663 Clamping nut M 16x1,5 1
0009 W3T172902 Diaphragm 5
0010 W3T168917 o-ring d 75,87 x 2,62 5
0011 W3T159664 Valve stem 5
0012 W3T168867 o-ring d 40 x 3 5
0013 W3T168914 Spring d 6,3 x 11,9 1
0014 W3T161434 o-ring d 8 x 2 5
0015 W3T159656 Valve stem 1
0016 W3T172724 o-ring d 20,22 x 3,53 5
0017 W3T159674 Diaphragm 8
0018 W3T172903 Spring 1
0019 W3T173063 Snap ring 5
0020 W3T159880 Anti-syphon unit 1
0021 W3T163614 Set of o-rings 5
0022 W2T506089 Injector throat, Nr. 140 W 3,57 mm 1
0023 W2T507416 Injector tailway 'F' 1
0024 W3T169066 o-ring d 12,37 x 2,62 5
0025 W3T172796 o-ring d 15,54 x 2,62 5
Pos. Part No. Description Quant.
0001 W3T168861 o-ring d 25 x 2,5 1
0002 W3T161434 o-ring d 8 x 2 1
0003 W3T169066 o-ring d 12,37 x 2,62 2
0004 W3T168988 o-ring d 68 x 2 1
0005 W3T172921 o-ring d 10 x 4 1
0006 W3T172724 o-ring d 20,22 x 3,53 1
0007 W3T169068 o-ring d 13,94 x 2,62 2
0008 W3T173010 o-ring d 28,17 x 3,53 1
0009 W3T172725 o-ring d 32,92 x 3,53 1
