7. Drawings V10k automatic
60
EN
Injector W3T171367 (1")
*) Silicone grease
W3T165077 ; pos. 23 sealed with teflon tape.
Pos Part no. Description Qty.
1 W3T159661 Seat PVC, 1" Injector 1
2 W3T161480 O-ring d13x2/FPM 1
3 W3T171124 Body PVC, 1" Injector 1
4 W3T161296 Plug GPN 610 U 28 1
5 W3T172921 O-ring d10x4/75FPM602 1
6 W3T170187 Seat PVC, 1" Injector 1
7 W3T172822 O-ring d15,54x2,62/FPM 2
8 W3T172899 O-ring d23,47x2,62/75FPM602 1
9 W3T161113 Spring TANTALOY 61,d24 1
10 W3T159663 Clamping nut PVC, M16x1,5 , 1" Injector 1
11 W3T172902 Diaphragm PTFE, 1" Injector 1
12 W3T168917 O-ring 75FPM602, ø75,87x2,62 1
13 W3T171119 Cover PVC, 1" Injector 1
14 W3T172900 Washer DIN 125 A, 8,4 mm, Monel 6
15 W3T172901 Screw DIN 931/M8 x 40/Monel 6
16 W3T159664 Valve stem PVC, 1" Injector 1
17 W3T159665 Plug PVC, 1" Injector 1
18 W3T168867 O-ring d40x3/FPM 1
19 W3T168914 Spring 1
20 W3T161434 O-ring d8x2/75FPM602 1
21 W3T159656 Valve stem PVC, 1" Injector 1
22 W3T159666 Plug PVC, 1" Injector 1
23 W3T168893 Plug PVC-U; 1/4-18NPTx21 2
24 W3T161279 Plug GPN 610 U 25 1
25 W2T507291 Union end PVC-U; d20 1
26 W2T506920 Union nut PVC-U; d20 1
27 W3T172724 O-ring d20,22x3,53/FPM 1
28 W3T161278 Plug GPN 610 U 18 1
29 W2T507548 Name plate 1
