7. Drawings V10k automatic
62
EN
Injector W3T171368 (1")
*) Silicone grease
W3T165077 ; pos. 23 sealed with teflon tape.
Pos Part no. Description Qty.
1 W3T159661 Seat PVC, 1" Injector 1
2 W3T161480 O-ring d13 x 2/FPM 1
3 W3T171118 Body PVC, 1"Inj., Anti-syph. 1
4 W3T161296 Plug GPN 610 U 28 1
5 W3T172921 O-ring d10 x 4/75FPM602 1
6 W3T170187 Seat PVC, 1" Injector 1
7 W3T172822 O-ring d15,54 x 2,62/FPM 2
8 W3T172899 O-ring d23,47 x 2,62/75FPM602 1
9 W3T161113 Spring TANTALOY 61,d24 1
10 W3T159663 Clamping nut PVC, M16 x 1,5, 1" Injector 1
11 W3T172902 Diaphragm PTFE, 1" Injector 1
12 W3T168917 O-ring 75FPM602, ø75,87 x 2,62 1
13 W3T171119 Cover PVC, 1" Injector 1
14 W3T172900 Washer DIN 125 A, 8,4 mm, Monel 6
15 W3T172901 Screw DIN 931/M8 x 40/Monel 6
16 W3T159664 Valve stem PVC, 1" Injector 1
17 W3T159667 Clamping screw 1
18 W3T168867 O-ring d40 x 3/FPM 1
19 W3T168914 Spring 1
20 W3T161434 O-ring d8 x 2/75FPM602 1
21 W3T159656 Valve stem PVC, 1" Injector 1
22 W3T159666 Plug PVC, 1" Injector 1
23 W3T168893 Plug PVC-U; 1/4-18NPT x 21 2
24 W3T161279 Plug GPN 610 U 25 1
25 W2T507291 Union end PVC-U; d20 1
26 W2T506920 Union nut PVC-U; d20 1
27 W3T172724 O-ring d20,22 x 3,53/FPM 1
28 W3T161278 Plug GPN 610 U 18 1
29 W2T507548 Name plate 1
40 W3T159669 Collet 1
41 W3T159674 Diaphragm 2
42 W3T159670 Valve stem guide PVDF, 1" Injector 1
43 W3T172903 Spring d18,2, V2A 1
44 W3T159671 Clamping disk PVC, 1" Injector 1
45 W3T159672 Diaphragm holder PVDF, 1" Injector 1
46 W3T159668 Separator PVC, 1" Injector 1
47 W3T173063 Securing clip POM-s; d12 1
