7. Drawings V10k automatic
66
EN
Anti‐syphon‐Injector W3T171370 (3/4")
*) Apply a thin coat of special grease W2T503995
Pos. 29: sealed with silicone grease W3T165077
Pos Part no. Description Qty.
1 W3T159655 Inlet screw PVC, 3/4" Injector 1
2 W3T168861 O-ring d25 x 2,5/FPM 1
3 W3T161434 O-ring d8 x 2/75FPM602 1
4 W3T159656 Valve stem PVC, 1" Injector 1
5 W3T171120 Body PVC, 3/4" Injector 1
6 W3T158460 Valve seat PVC, UNF½"-20Gg 1
7 W3T169066 O-ring d12,37 x 2,62/FPM 2
8 W3T168988 O-ring d68 x 2/FPM 2
9 W3T161483 Diaphragm PTFE, 3/4" Injector 3
10 W3T158461 Clamping nut PVC, UNF½"-20Gg 2
11 W3T165194 Spring d=1,6; Tantaloy 61 1
12 W3T168914 Spring 1
13 W3T159657 Valve stem PVC, 3/4" Injector 1
14 W3T172921 O-ring d10 x 4/75FPM602 1
15 W2T506923 Union nut PVC-U; d63 2
16 W3T158545 Guide pin PVDF, 3/4" Injector 2
17 W3T169065 O-ring d6,07 x 1,78/FPM 2
20 W3T159658 Bottom cover PVC, 3/4" Injector 1
21 W3T161484 Spring d21,3 3/4" Injector 1
22 W3T158546 Disk PVC, 3/4" Injector 1
23 W3T159673 Body PVC, 3/4" Injector 1
29 W3T168893 Plug PVC-U; 1/4-18NPT x 21 1
32 W3T161278 Plug GPN 610 U 18 2
33 W2T507548 Name plate 68 x 35 1
34 W3T171695 Diaphragm d74,5 x d12,7/67FPM581 1
35 W3T161275 Plug GPN 610 U 7 2
