EVS XT-3 User Manual

Video and Codecs
The codecs modules allow connections for recording and playback of video material.
Each connector on a codec module is connected to the corresponding J connector on the
COD A or COD B module of a V3X board.
See section "V3X Video and Reference Boards" on page 85 for more details on each
connector specific usage according to the different configurations.
The following video and codecs connectors layouts are available according to your
configuration:
Config Layout Description
222 2-channel
version
444 4-channel
version (open
config.)
Digital Audio
The audio inputs and outputs are available on multi-pin (DA-15) connectors for audio
signal inputs and outputs in digital format.
See section "Audio Connections" on page 62 for more details on the DA-15 connectors
pinout according to the different configurations.
HARDWARE TECHNICAL REFERENCE MANUAL XT3 Server 12.05
5. Hardware Installation and Cabling 59
