Bandwidth and RT Channels at 50Hz (PAL)
Codec
Field
Rate
(Hz)
Video
Bitrate
(Mbps)
Fields/
Block
Block-based
bandwidth
(MB/s)
Max. RT
Channels
Apple ProRes 422 LT 50.00 85 34 11.7 34
AVC-Intra 100 50.00 111 27 14.8 27
XAVC-Intra HD 50.00 111 27 14.8 27
Avid DNxHD® 120 50.00 120 24 16.6 24
Apple ProRes 422 SQ 50.00 120 24 16.6 24
Avid DNxHD® 185 50.00 185 16 25.0 16
Apple ProRes 422 HQ 50.00 185 16 25.0 16
XAVC-Intra 4K 50.00 500 6 66.6 6
Bandwidth and RT Channels at 100Hz (PAL SLSM 2x)
Codec
Field
Rate
(Hz)
Video
Bitrate
(Mbps)
Fields/
Block
Block-based
bandwidth
(MB/s)
Max. RT
Channels
XAVC-Intra 4K 100.00 500 3 133 3
Bandwidth and RT Channels at 150Hz (PAL SLSM 3x)
Codec
Field
Rate
(Hz)
Video
Bitrate
(Mbps)
Fields/
Block
Block-based
bandwidth
(MB/s)
Max. RT
Channels
Apple ProRes 422 LT 150.00 85 11 35.3 11.3
AVC-Intra 100 150.00 111 9 44.4 9.0
XAVC-Intra HD 150.00 111 9 44.4 9.0
Avid DNxHD® 120 150.00 120 8 50.0 8.0
Apple ProRes 422 SQ 150.00 120 8 50.0 8.0
Avid DNxHD® 185 150.00 185 5 75.0 5.3
Apple ProRes 422 HQ 150.00 185 5 80.0 5.0
