Bandwidth and RT Channels at 59.94Hz (NTSC)
Codec
Field
Rate
(Hz)
Video
Bitrate
(Mbps)
Fields/
Block
Block-based
bandwidth
(MB/s)
Max. RT
Channels
Apple ProRes 422 LT 59.94 100 34 14.1 28.3
AVC-Intra 100 59.94 111 33 14.5 27.5
XAVC-Intra HD 59.94 111 33 14.5 27.5
Avid DNxHD® 145 59.94 145 23 20.8 19.2
Apple ProRes 422 SQ 59.94 145 25 19.2 20.8
Avid DNxHD® 220 59.94 220 16 30.0 13.3
Apple ProRes 422 HQ 59.94 220 16 30.0 13.3
XAVC-Intra 4K 59.94 600 7 68.5 5.8
Bandwidth and RT Channels at 120Hz (NTSC SLSM 2x)
Codec
Field Rate
(Hz)
Video
Bitrate
(Mbps)
Fields/
Block
Block-based
bandwidth
(MB/s)
Max. RT
Channels
XAVC-Intra 4K 119.88 600 3 160 2.5
Bandwidth and RT Channels at 180Hz (NTSC SLSM 3x)
Codec
Field
Rate
(Hz)
Video
Bitrate
(Mbps)
Fields/
Block
Block-based
bandwidth
(MB/s)
Max. RT
Channels
Apple ProRes 422 LT 179.82 85 11 42.3 9.4
AVC-Intra 100 179.82 111 11 43.6 9.1
XAVC-Intra HD 179.82 111 11 43.6 9.1
Avid DNxHD® 179.82 145 8 62.5 6.4
Apple ProRes 422 SQ 179.82 145 8 57.4 6.9
Avid DNxHD® 179.82 220 5 89.9 4.4
Apple ProRes 422 HQ 179.82 220 5 89.9 4.4
