IN Channels
Connector label HDMode
IN 4A SDI input of the IN1 channel.
IN 4B SDI input of the IN2 channel.
OUT 4A SDI monitoring output of the IN1 channel.
OUT 4B SDI monitoring output of the IN2 channel.
OR
SFP 4C IP input of the IN1&2 channels and
IP monitoring of the IN1&2 channels
SFP 4D
