Switch Cabling
The internal switch module provides a more efficient communication between the H3XP
board on one hand, and the MTPC board and MV4 board on the other hand.
The internal switch relies on the internal LAN, an IP-based network inside the EVS server.
The following connectors are available on the internal switch module and need to be
cabled as described below:
Connector Cable Color Connection
#1 Red Connection to the HS873 motherboard on the MTPC
board
#2 Green Connection to the MV4 module (multiviewer) on the
MTPC board
#3 White Connection to the EVS LNK connector on the rear
panel (not currently used)
#4 Blue Connection to the PCLAN 1 connector on the rear
panel
#5 Yellow Connection to the PCLAN 2 connector on the rear
panel
