Functional characteristics
MIG/MAG welding
099-5TLPXQ-EW501
29.01.2021
5.2.4.1 Welding procedure
After setting the basic parameters you can switch between the welding procedures MIG/MAG, forceArc,
wiredArc, rootArc und coldArc (if there is a corresponding combination of the basic parameters). The pro-
cess change will also change the JOB number, but the basic parameters remain unchanged.
Figure 5-6
5.2.4.2 Operating mode
The operating mode determines the process sequence controlled by the welding torch. Detailed descripti-
ons of the operating modes > see 5.2.8 chapter.
Figure 5-7
