EWM LP-XQ - Expert Menu (MIG;MAG)

Functional characteristics
MIG/MAG welding
40
099-5TLPXQ-EW501
29.01.2021
5.2.9 Expert menu (MIG/MAG)
The Expert menu has adjustable parameters stored that don’t require regular setting. The number of pa-
rameters shown may be limited, e.g. if a function is deactivated.
A
B
A
B
A
A
A
A
A
B
B
B
B
B
B
B
A
A
B
A
Figure 5-24
Display
Setting/selection
Ignition current
Setting range in percent: depending on main current
Setting range, absolute: Imin to Imax.
Correction of arc length in start program P
START
Start time (duration of ignition current)
Slope time of start program P
START
to main program P
A
Slope time of main program P
A
to end program P
END
End-crater current
Setting range in percent: depending on main current
Setting range, absolute: Imin to Imax.
Correction of arc length in end program P
END
