Functional characteristics
Special parameters (advanced settings)
099-5TLPXQ-EW501
29.01.2021
Correction operation, threshold value setting
0 = ------- correction operation switched off (Ex works)
1 = ------- correction operation on
"Main program (PA)" flashing
Program switching with standard welding torch
0 = No program switching (factory setting)
1 = ------- Special latched
2 = ------- Special latched (n-cycle active)
3 = ------- Special latched (n-cycle sequence from any program)
Tapping start for latched and special latched operation
0 = ------- no 4-cycle inching start
1 = ------- 4-cycle inching start possible (ex works)
One or two-wire feed operation
0 = ------- single operation (Ex works)
1 = ------- dual operation, this unit is the "master"
2 = ------- dual operation, this unit is the "slave"
Special latched tapping time
0 = tapping function switched off
1 = 300ms (Ex works)
2 = 600ms
JOB list changeover
0 = ------- task-oriented JOB list
1 = ------- actual JOB list (Ex works)
2 = ------- actual JOB list, JOB changeover activated via accessories
Lower limit remote JOB switching
JOB range of the function torches (PM 2U/D, PM RD2)
Lower limit: 129 (ex works)
Upper limit remote JOB switching
JOBarea of the function torch (PM 2U/D, PM RD2)
Upper limit: 169 (ex works)
HOLD function
0 = ------- HOLD values are not displayed
1 = ------- HOLD values are displayed (Ex works)
Block JOB mode
0 = ------- Block JOB mode not enabled (Ex works)
1 = ------- Block JOB mode enabled
Program selection with standard torch trigger
0 = ------- no program selection (Ex works)
1 = ------- program selection possible
Mean value display for superPuls
0 = ------- Function switched off.
1 = ------- Function switched on (ex factory).
Predefined pulse arc welding process in the PA program
0 = ------- Predefined pulse arc welding process in the PA program is disabled.
1 = ------- If the superPuls and welding process switching functions are available and acti-
vated, the pulse arc welding process is always executed in the main program
PA (ex factory).
Predefined absolute value for relative programs
Start program (P
START
), down-slope program (P
B
) and end program (P
END
) can be set re-
lative to the main program (P
A
) or in an absolute manner, as desired.
0 = ------- Relative parameter setting (ex factory)
1 = ------- Absolute parameter setting
