Operation
22
Edition 04/09.2002 EXAKT 35 / 50
Unit set-up (Fig. 13)
10. At first adjust the smallest possible
roller gap (position I on both hand-
wheels).
11. Allways use a spatula to drop product
into the hopper.
12. Switch on the unit – with these gap
settings the product should be ground
to the maximum fineness (maximum
finenss may require more than one
grinding.).
13. Continue applying the product using
a spatula.
Fig. 13: Roller gap adjustment
Note
Use a separate spatula for taking the product off the scraper to
insure that the finely ground product is not contaminated with
yet to be ground product.
Throughput adjustment (Fig. 14+15)
14. The throughput can be increased by
gradually increasing the rear roller
gap as indicated by the arrow (Fig.
14).
Fig. 14: Roller gap increase
Note
If the rear roller gap is increased too much, too much product
will be fed to the narrow front roller gap. This causes the
product to spread out laterally over the front roller (small arrows
in Fig. 14).
Continued ...
