Exakt 35 - EXAKT 50 Scraper Systems

Spare parts and auxiliary equipment
42
Edition 04/09.2002 EXAKT 35 / 50
10.5 EXAKT 50 scraper systems
Fig. 26: EXAKT 50 scraper systems
Item Part no. Description Quantity
Variation (version or style) 1
1 11330 Metal scraper, complete
2 11350 Metal scraper plate
3 11340 Scraper socket
Variation (version or style) 2
4 11360 Plastic scraper
Variation (version or style) 3
5 11370 Universal scraper socket (complete)
6 11290 Scraper knife, yellow, Fiberglas reinforced epoxy
resin
7 11310 Scraper knife, red, PVC-NL
8 11280 Scraper knife, metal, nickel-plated
9 11380 Scraper knife, metal, hard-chromium-plated
(cannot be used in conjunction with steel rollers)
10 11390 Scraper knife, ceramic, Al
2
O
3
Warning – Danger of equipment damage due to
incompatible roller/scraper materials!
Specific scraper (knife) materials are incompatible with certain
roller materials.
See section 10.6 for information on acceptable combinations of
rollers and scraper knives.
4 5 6, 7, 8, 9, 10
2 3
1
